The AEC-Q200 Ultra-Low ESR X8G range offers a very stable X8R High Q material system that provides excellent low loss performance. The range is tested and approved to automotive specification AEC-Q200.
Optimized for lowest possible ESR, the electrode system provides low metal losses resulting in flatter performance curves and reduced losses at higher frequencies.

An extended operating temperature range of -55°C to +150°C accommodates modern high density micro electronics requirements. This range of high frequency capacitors is suitable for many applications where economical, high performance is required.

Operating Temperature
-55°C to +150°C (EIA X8G)
Temperature Coefficient (Typical)
0 ± 30 ppm/°C (EIA X8G)
Insulation Resistance
Time constant (Ri xCr) (whichever is less) 100GΩ or 1000s
Q Factor
>2000 @ 1MHz
